General Information |
||
|---|---|---|
| PD No. | VT-LEM07224(i)-M12-MP10 | |
| PD Line | M12 Series | |
| Type |
Standard FA Lens
|
|
Optical Specifications |
||
|---|---|---|
| Resolution | 10 Mega Pixels | |
| Image Size | 1/2.3" CCD/CMOS | |
| Focal length | 7.2 mm | |
| Aperture, F/# | F2.4 | |
| Back Focus | 7.23 mm | |
| M.O.D | 0.3 m | |
|
FOV(D×H×V) |
D:57° H:47° V:37° |
|
| TV Distortion | NA | |
| TTL | 32.37±0.3 mm | |
| Relative Illumination | NA | |
| Iris | Fixed | |
| Max Chief Ray Angle | NA | |
| Coating Wavelength |
400-950 nm
|
|
Design |
||
|---|---|---|
| Mount | S-mount(M12) | |
| Filter Size | NA | |
| Built-in ir-cut | NA | |
| Lens Effective Diameter | Φ13.3 / Φ7.5 | |
| Dimension | Φ19 × 26.14±0.3 mm | |
| Working Temperature | -10 - 50°C（Operating），-20 - 60°C（Storage） | |
| Weight | NA | |
