Information |
||
|---|---|---|
| PD No. | iBX-SWX992J | |
| PD Line | iBoostX Series | |
Sensor |
||
|---|---|---|
| Sensor | IMX992 | |
| Shutter | Global | |
| Sensor Size | 1/1.4” (8.94x7.09) | |
| Resolution | 2560x2048 | |
| Pixel Size | 3.45 μm | |
| Frame Rate | 131@ 560×2048 252@1280×1024 | |
| Color Type | SWIR | |
EMVA Data |
||
|---|---|---|
| Dynamic Range(typical) | 51.36dB | |
| SNR(typical) | 48.45dB | |
Camera Data |
||
|---|---|---|
| Interface | CoaXPress 2.0 (CXP-10 x 1) | |
| Pixel Bit Depth | 8bit/10 Bit/ 12bit | |
| Synchronization |
● Soft Trigger ● Hardware Trigger ● Free Run |
|
| I/O | 1 opto-isolated input, 1 opto-isolated output, 2 non-isolated I/O | |
| Power Supply | PoCXP / 12V | |
Design |
||
|---|---|---|
| Dimension | 80mm×80mm×45.5mm | |
| Lens Mount | C-Mount | |
| Working Temperature | -40~85 °C (Storage), -20~60°C ( Operating ) | |
| Weight | 390g | |
Software Environment |
||
|---|---|---|
| Driver, SDK | iBoostX | |
| Operating System | Windows，Linux | |
