Information |
||
|---|---|---|
| PD No. | CP- | |
| PD Line | Mars Series | |
Sensor |
||
|---|---|---|
| Sensor Vendor | CMOSIS | |
| Sensor | / | |
| Sensor Type | CMOS | |
| Resolution | 8192 px x 1 px | |
| Pixel size | 7 μm x 7 μm | |
| Line Rate | 74 K | |
| Mono/Color | Mono | |
| Image Format | Mono8/10/10Packed/12/12Packed | |
| Pixel Clock Speed | 32M/48M/68M/85 MHz | |
EMVA Data |
||
|---|---|---|
| Dynamic range (typical) | 66.0 dB | |
| Exposure Time | 8μs~100ms | |
Camera Data |
||
|---|---|---|
| Interface | CameraLink | |
| Synchronization |
● Soft Trigger ● Hardware Trigger ● Free Run |
|
| I/O | Differential/single-ended inputs x 2; Differential/single-ended outputs x 2; Differential/single-ended configurable input and output x 1; GPIO x 1 | |
| Power Supply | DC12V~24V | |
Design |
||
|---|---|---|
| Dimension (L x W x H) | 80.0 × 80.0 × 48.0 mm | |
| Lens Mount | M72*0.75 (FBL 12) | |
| Working Temperature | -30- 50°C（Operating），-30- 80°C（Storage） | |
| Weight（Typical） | 390g | |
Software Environment |
||
|---|---|---|
| Driver , SDK | Mars Series Camera Secondary Development Kit（iCentral）or Third-party Software meeting with CameraLink Protocol | |
| Operating System | Windows | |
| Conformity | CameraLink / GenICam | |
