General Information |
||
|---|---|---|
| Model | VT-LEN2028MP10 | |
| PD Line | LEN Series | |
| Type | FA Lens | |
Optical Specifications |
||
|---|---|---|
| Resolution | 10 Mega Pixels | |
| Image Size | 2/3" CCD/CMOS | |
| Focal length | 20±5%mm | |
| Aperture, F/# | F2.8±10% | |
| Flange Back | 17.526 mm | |
| Optical back focus | 13.45 ～ 15.48mm | |
| Mechanical back focus | <13.526mm | |
| M.O.D | 0.2 m | |
|
FOV |
28.6° ×23.33° ×17.35° | |
| TV Distortion | <-0.60% | |
| Relative illumination | 43% | |
| Iris | Manual | |
| Focus | Manual | |
| Coating Wavelength | 400-950 nm | |
Mechanical Parameters |
||
|---|---|---|
| Mount | C-mount | |
| Filter Size | NA | |
| Dimension | Φ29 × 26 mm | |
| Temperature Range | -10- 50°C（Working），-20- 60°C（Storage） | |
| Weight | 150 g | |
