LEO 8KT2-34CC(TDI)
  • 8K @33.7 KHz
  • Adopts CameraLink interface to transmit data
  • Supports four configuration modes: Base, Medium, 80-bit
  • Compatible with CameraLink Vision Protocol, GenlCam Standard, and the third-party software based on these protocol and standard
  • Support Windows
Inquire now
Shop now
Product Description
Technical Drawing
Documents & Downloads

Information

PD No. LEO 8KT2-34CC
PD Line LEO Series

Sensor

Resolution 8192 px x 6 px
Pixel size 5 μm
Pixel Clock 40 MHz,66 MHz,80 MHz,85 MHz
Tap Type 1/2/10 Taps
Line Rate 10.1 kHz@Base,20.2 kHz@Medium,33.7 kHz@80-bit
Mono/Color Color
Image Format RGB8,BGR8,Mono8

EMVA Data

Dynamic range (typical) 62 dB
Exposure Time 3μs~10ms

Camera Data

Interface CameraLink
Synchronization

● Soft Trigger

● Hardware Trigger

● Free Run

I/O Configurable output and input × 4
Power Supply DC12-24V
Power Consumption 12V @ 9.6W

Design

Dimension(L x W x H) 84.0 mm × 84.0 mm × 46.2 mm
Lens Mount M72*0.75(FBL 12)
Operating Temperature -20- 55°C(Working),-30- 80°C(Storage)
Weight 480g

Software Environment

Driver&SDK LEO Series Camera Software Suite or 3rd party Cameralink Software
Operating System Windows
Conformity Cameralink and GenICam
