LEO 150MS-6XC
  • 151MP resolution @6.2 fps
  • Adopts CXP-6 interface to transmit data
  • Global shutter CMOS, high dynamic range, good signal-to-noise ratio, excellent image quality
  • Compatible with CoaXPress Protocol, GenlCam Standard, and the third-party software based on these protocol and standard
  • Support Windows
Inquire now
Shop now
Product Description
Technical Drawing
Documents & Downloads

Information

PD No. CP-
PD Line LEO Series

Sensor

Sensor Vendor Sony
Sensor IMX411
Shutter Rolling Shutter
Sensor Size 66.7 mm
Sensor Type CMOS
Resolution 14208 px x 10640 px
Pixel size 3.76 μm x 3.76 μm
Frame Rate 6.2 fps
Mono/Color Color

EMVA Data

Dynamic range 78.7 dB
Signal-to-Noise Ratio 46.4 dB

Camera Data

Interface CoaXPress
Pixel Bit Depth 8 / 10 / 12 / 16 bits
Synchronization

● Soft Trigger

● Hardware Trigger

● Free Run

I/O 1 opto-isolated input, 1 opto-isolated output, 1 RS232
Power Supply 12-24 VDC

Design

Dimension(L x W x H) 100 × 100 × 74.3 mm
Lens Mount M72
Operating Temperature 0- 50°C(Working),-30- 70°C(Storage)
Weight 1000g

Software Environment

Driver&SDK Frame grabber software complies with CoaXPress protocol
Operating System Windows
Conformity Coaxpress Vision and GenICam
