Information |
||
|---|---|---|
| PD No. | CP-0883 | |
| PD Line | LEO Series | |
Sensor |
||
|---|---|---|
| Sensor Vendor | Sony | |
| Sensor | IMX 296 | |
| Shutter | Global Shutter | |
| Sensor Size | 1/2.9" | |
| Sensor Type | CMOS | |
| Resolution | 1440 px x 1080 px | |
| Pixel size | 3.45 μm x 3.45 μm | |
| Frame Rate | 65.2 fps | |
| Mono/Color | Mono | |
EMVA Data |
||
|---|---|---|
| Dynamic range | 74.0 dB | |
| Exposure time | 超短曝光模式：1 μs ~ 14 μs; 标准曝光模式：15 μs ~ 10 sec | |
Camera Data |
||
|---|---|---|
| Interface | WTB | |
| Pixel Bit Depth | 8 / 10 / 12 bits | |
| Synchronization |
● Soft Trigger ● Hardware Trigger ● Free Run |
|
| I/O | Opto-isolated input x 1, opto-isolated output x 1, and bi-directional custom non-isolated I/O x 1 | |
| Power Supply | 9-24 VDC | |
Design |
||
|---|---|---|
| Design | Compact industrial design | |
| Dimension (L x W x H) | 29 mm × 29 mm × 21.2 mm | |
| Lens Mount | M12 | |
| Working Temperature | 0- 50°C（Operating），-30- 70°C（Storage） | |
| Weight | 25g | |
