Information |
||
|---|---|---|
| PD No. | CP-0704 | |
| PD Line | CLW2 Series | |
| Type | Bi-Telecenteic Lenses | |
Lens Data |
||
|---|---|---|
| Mag.(x) | 0.8x | |
| WD | 130±2 mm | |
| MAX. Sensor Size | 11.0 Φmm(2/3") | |
| Field of View |
1/2” (6.4x4.8) 8.0x6.0 1/1.8” (7.13x5.37) 8.9x6.7 2/3” (8.8x6.6) 11.0x8.3 |
|
| F/# | F12.6 | |
| MTF | >65lp/mm | |
| Distortion | <0.1% | |
| Telecentricity | <0.1° | |
| NA | 0.0316 | |
| Resolution | 10.6 μm | |
| D.O.F | 1.6 mm | |
Design |
||
|---|---|---|
| Lens Mount | C-mount | |
| With Coaxial Light | Yes | |
|
Aperture adjustment |
No | |
| Lenght | 121.4 mm | |
| Temperature | -10 - 50°C（Operating），-20 - 60°C（Storage） | |
