Information |
||
|---|---|---|
| PD No. | CP-0704 | |
| PD Line | BTL Series | |
| Type | Bi-Telecentric Lenses | |
Lens Data |
||
|---|---|---|
| FOV | 120 Φmm | |
| Mag.(x) | 0.138x | |
| WD | 273±5 mm | |
| Max. Sesnor Size | 16.6(1") Φmm | |
| Field of View |
1.1" KAI-04050(12.85x9.64) 93.1x69.9 1.1" CMV4000(11.26x11.26) 81.6x81.6 1.1" ICX674/694/814(12.5x10.0) 90.6x72.5 |
|
| F/# | F6.5 | |
| MTF | >140lp/mm | |
| D.O.F | ±33.4 mm@F16 | |
| Distortion | <0.1% | |
| Telecentricity | <0.1° | |
| I/O | 590±5 mm | |
Design |
||
|---|---|---|
| Lens Mount | C-mount | |
| Length | 299.8 mm | |
| Temperature | -10 - 50°C（Operating），-20 - 60°C（Storage） | |
| Weight | 4.3 Kg | |
