BTL-0.038XH-410-118(LM)

1. Optimized for 1/2.5"~1.1" C-Mount cameras;
2. Largest FOV from 26mm upto 300mm;
3. Excellent resolution for high pixel cameras;
4. Low distortion, good telecentricity, big aperture and big depth of field for high end application.

Inquire now

Shop now

Product Description

Technical Drawing

Documents & Downloads

Information
	PD No.	CP-0704
	PD Line	BTL Series
	Type	Bi-Telecentric Lenses

Lens Data
	FOV	240 Φmm
	Mag.(x)	0.038x
	WD	410±6 mm
	Max. Sesnor Size	9.0(1/1.8") Φmm
	F/#	F4.6
	MTF	>200lp/mm
	D.O.F	±313 mm@F11
	Distortion	<0.1%
	Telecentricity	<0.1°
	I/O	972±6 mm
