VT-LEMF3528MP29-0.1X
1. Wide wavelength from 400~950nm
2. Optical performance is superior to lens of SLR
3. Support 5μm pixel 29MP High resolution
4. High Cost Performance
Inquire now
Shop now
Product Description
Technical Drawing
Documents & Downloads

General Information

PD No. CP-1047
PD Line Large Format Series
Type Large Format F/T mount lenses


Optical Specifications

Resolution 29 MP
Image Size 45.3 mm
Focal length 35.0 mm
Aperture, F/# F2.8
Mag. Range 0.01x-0.1x
Standard Mag. 0.03x
FFL 46.5 mm
M.O.D 0.4 m
FOV(D×H×V)

D:65°

H:/°

V:/°

TV Distortion <0.5%
TTL 114.1
Relative Illumination NA
Focus Range NA
Iris Manual
Focus Manual
Max Chief Ray Angle NA
Coating Wavelength 400-950 nm


Mechanical Parameters

Mount F-mount
Filter Size M67 × 0.75
Built-in ir-cut NA
Front/Rear Effective Dia. Φ12.2
Dimension Φ69 × 67.6 mm
Temperature Range -10- 50°C(Working),-20- 60°C(Storage)
Weight NA

Standard FA industrial lens
